Program 10 : System Conﬁguration Setup

10-30 : SIP Authentication Information

UX5000 Software Program Manual Programming ◆ 81

Terminal Programming Instructions

To enter data for Program 10-30 (SIP Authentication Information):

1. Enter the programming mode.

2. 10 30

3. Enter the number of the item you want to program.

4. Enter data for the item you selected + HOLD.

5. Enter data for the next item in the program.

Press MIC once to enter a new item number.

Press MIC until you’ve exited that series’s programming section.

10-30-02

User Name

back

↑ ↓ select

10-30-nn

nnnnn

← →
